Xiaomi Vacuum Robot Vacuum S10

Main Features
• Laser navigation, precisely detects surroundings
• Raised LDS sensor with 360-degree detection range
• 4000Pa powerful suction fan blower
• Zigzag and Y-shape cleaning routes
• Multiple sensors fewer bumps and obstacles
• 3200mAh large battery capacity
• Smart water tank protect floors from water damage
• Connect Mi Home app to control

Product Specifications
• Model Number: B106GL
• Main Unit Dimensions: 350x94.5mm
• Rated Power: 45W
• Rated Voltage: 14.8V⎓
• Charging Voltage: 20V⎓
• Net Weight: 3.6kg

Package Contents
• Main unit x1 | Main brush x1(Pre-installed) | 2-in-1 water tank and dust container x1(Can be used in either Vacuum or Mop mode)A | Side brush x1 | Brush cover x1(Pre-installed) | Pad x1(Pre-installed on mop frame) | Mop frame x1 | Power adapter x1 | Charging dock x1 | Cleaning brush x1(Open lid to access) | User manual x1

Collision Sensor *2
• Detect when the infrared signal is blocked to determine whether there are obstacles ahead.

Cliff Sensor *4
• The strength of the received infrared signal is used to judge height of the drop and prevent the robot from falling.
• Effective detection range: 1–10cm

Speed Sensor *2
• Primarily designed to measure the wheel speed.
• No distance measurement function

Induction Sensor *1
• Detect the presence of functional components (such as the water tank) through magnetic field induction between the sensor and a magnet.
• No distance measurement function

Gyroscope (IMU) *1
• Detect the position of the robot via a 3-axis gyro sensor.
• No distance measurement function

Radar Sensor *1
• Use radar distance measurements to judge whether there are obstacles ahead and how far away they are, and assist the robot as it plans its path.
• Specified range: approx. 0.16m–8m

Recharge Sensor *1
• Send and receive infrared signals to align the robot with the charging dock.
• Effective range: approx. 4m
